FUSE TUBE – FUSE CUTOUT ACCESSORIES
GENERAL FEATURES:
- PRODUCT TYPE: Fuse cutout
- Inner: vulcanized fiber tubes
- Outer:fiberglass reinforced epoxy resin winding tubes
- SURFACE: UV resistant insulation Painting
- SIZE: 25.4MM, 30MM
- LENGTH: 230MM – 1200MM
- APPLICATION: FUSE CUTOUT
- OEM: AVAILABLE
FUSE CUTOUT TUBE PARAMETERS:
Rated Current | Section Length (mm) | O.D. (mm) | Meddle layer D. (mm) | O.D. (mm) |
100A | 230 ~ 1200 | 25.4 | 12.7 | 18.24 |
200A | 230 ~ 1200 | 30 | 16 | 24 |
FUSE CUTOUT TUBE DESCRIPTION:
High voltage fiberglass fuse tube for fuse cutout is made of alkali-free glass fabric and binded with epoxy resin, in heat-rolling and tightening, baking and curing, with high mechanical property and stable electrical property in high humidity, suitable for being used as insulation structural parts of mechanical, electrical and electronic equipment.
Material:
Inner: vulcanized fiber tubes
Outer:fiberglass reinforced epoxy resin winding tubes
Surface: UV resistant insulation Painting
Production process:
Vulcanized fiber tube was wrapped by fiber glass impregnate epoxy resin ,The angle of wind is optimized to provide a finished tube with good tensile and anti explosion strength.Vulcanized fiber tube becomes an integral tube liner which have the property of gas-generating and arc-quenching characteristics. Epoxy resin fiberglass tube property of strength and water resistance. The fiberglass tube is usually coated with UV resistant paint in gray color.
Advantage:
no-spark generating, char layer forming to prevent liner from excessive ablation, and the optimum amount of arc-quenching gas generating.
OUR SERVICES:
- OEM / ODM Manufacturing welcome: Product, Package…
- Sample order
- We will reply you for your inquiry in 24 hours.
- After sending, we will track the products for you once every two days, until you get the products.
- When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solve way for you.
OUR ADVANTAGES:
- Nearly 36 years professional production experience
- Annual production capacity of 1 million
- Professional R&D team
- Certified : IS0 9001
- 80% reorder customers
- Best factory price
